Cubicle – Blade Mounted Free Standing (BF)

TPI’s BF cubicle draws a simple top line by eliminating the over-head door brace. This extra top space makes the BF an excellent choice for low ceiling rooms. A recommended option for offices and restaurants needing a clean, upmarket tone.

With its stainless steel blade mounts, no panel touches the floor, allowing construction from classic structural board. This opens up a wide range of colours and textures and allows matching with other joinery finishes.

NOTE: This system can only be installed on a concrete slab.

Available as Supply & Install only.

How to Specify TPI’s Displayed Configuration

TPI BF33L Blade Mounted Free Standing in 33mm Decorated & 18mm Divisions MR P/Board. Door Furniture to be Metlam® Sera Round series. Aluminium to be Square Clear Anodised. Screw fixing.

Additional information

Standard Dimensions

Height: 1900mm (overall maximum)
Depth: 1600mm nominal
Frontal: 220mm minimum (w) for structural integrity
Doors: 1700mm (h) x 593mm – 600mm opening
Ambulant Doors: 1700mm(h) x 750 MM (w)
Floor Clearance: 200mm

Material Options

33mm Decorated MR P/Board
18mm Decorated MR P/Board (divisions only)

Door Furniture

Metlam Sera Round Satin Chrome Plated (standard)
Metlam Sera Round Black Designer (optional)
Metlam Sera Round Satin Bronze (optional)
Metlam® 300 Series SCP (optional)
Metlam® 700 Series SSS (optional)

Aluminium Profile

Square Clear Anodised
Square Powdercoated
