U-FIX Pedestal Mounted Overhead Braced (PO)

The PO is an enduring classic, the VW beetle of cubicles.  Strong, time tested and economical. The PO cubicle is the lowest cost design in every material used. The PO is found everywhere from Antarctica to Circular Quay. Functional, easy-to-clean with retro appeal. It’s a crowd-pleaser.
Available as Supply only
How to Specify TPI’s Recommended Configuration
TPI PO13CL Pedestal mounted Overhead braced. 13mm Compact Laminate. Pedestal to be 200mm Aluminium leg. With Modulux® Total Privacy Solution. Door Furniture to be Metlam Xcel series. Aluminium to be Square Clear Anodised. Screw Fixing.



Additional information

Additional information

Standard Dimensions

Height: 2000mm
Depth: 1600mm nominal
Frontal: 200mm minimum (w) for structural integrity
Doors: 1700mm (h) x 595mm (w) – 600mm opening
Ambulant Doors: 1700 (h) x 720-750mm (w)
Floor Clearance: 200mm

Material Options

13mm Compact Laminate

18mm Laminated Board

Pedestal Legs

200mm Aluminium leg (d 32mm)

Privacy Edge (optional)

TPI’s patented Modulux® Total Privacy Solution for the ultimate in cubicle privacy (available only in 13mm Compact Laminated, 12mm Laminated Acrylic doors and 19mm Nuvex doors).

Door Furniture

Metlam® Xcel series (standard)

Aluminium Profile

Square Clear Anodised
